Easily Molding Conductive Masterbatch High Electrical Capacity
Product Details:
| Place of Origin: | DONGGUAN, China |
| Brand Name: | SUGO |
| Certification: | ROHS, REACH |
Payment & Shipping Terms:
| Minimum Order Quantity: | 200 kgs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | 25kg per bag, paper bag with inner PE layer |
| Delivery Time: | 3-7 days |
| Payment Terms: | 100% T/T before shipment, or LC at sight |
| Supply Ability: | 1000TONS/M |
|
Detail Information |
|||
| Product Name: | Conductive Functional Masterbatch | Surface Resistivity: | Less Than 50 Ohms Before Mixing With Resin |
|---|---|---|---|
| Type: | Conductive Masterbatch | Advantage: | Good Dispersion Performance, Permanent Function Of Anti Static |
| Appearance: | Round Grannual | Usage: | PP/PE/PS Plastic |
| Samples: | Available,Free Of Charge | Standard Color: | Black |
| High Light: | conductive black masterbatch,electrically conductive masterbatch,Easily Molding conductivestatic dissipative plastic |
||
Product Description
Easily Molding Conductive Carbon Black Masterbatch High Electrical Capacity
Product Description
Conductive Carbon Black Master Batch
Our experience with carbon black processing translates very well to conductive applications. We offers conductive
compounds and masterbatches utilizing a variety of conductive carbon blacks and other additives. Carbon black
selection is critical when designing a conductive thermoplastic compound. Depending on which polymer base and
end use properties are required, certain types of carbon black may or may not be suitable for consideration.
Conductive carbon blacks can be used as fillers to transform insulating plastics into permanently conductive / anti static
materials. These conductive compounds offer the best price/performance ratio.
Optimal balance between conductivity, physical properties, and processability can be achieved using 5%–50% of carbon
black depending on the resin system and the grade of carbon black. Additional benefits include resistance to UV radiation
and oxidative degradation.
The conductive grades of carbon black are all characterized by small primary particle size, large surface area, high structure (interparticle agglomeration and branching), and a surface with low oxygen containing groups.
Typically, for a specific polymer system, the conductivity increases with
· Decreasing particle size
· Increasing surface area
· Increasing structure
· Decrease in the number of oxygen containing surface groups like -CO, -COOH, etc. of the carbon black.
The properties of the polymer system that affect the conductivity of a polymer-carbon black system are:
· The interfacial adhesion between the polymer and carbon black
· The crystallinity and crystallization characteristics of the polymer
· The morphology in case of alloys and co-polymers
· The inherent resistivity of the polymer
Moreover, the processing method, rheology, and the extent of carbon black dispersion in the polymer affect the conductivity of these compounds. These classes of compounds are widely used in:
· Packaging for static sensitive electronic and explosive devices
· Antistatic flooring and sheeting for hospitals, semiconductor industry, and mines
· Antistatic belting, hoses, and molded components for automotive, mining and electronics industry
· Power and telecommunications cable sheathing and shielding applications
Notice
1. Professional technical team to service all customers throughout the world.
2. Surface resistance can customized by order.
3. Masterbatch can be made according to customer's samples.
4. 100 % quality check before shipment.
5. Competitive price and delivery in time.
6. Welcome to contact us at any time.
| SUGO’s ESD compounds are formulated by combining carbon fiber,carbon powder, non-carbon based homogeneous materials and thermoplastic resins. These compounds meet the needs of many industries where permanent reduction of electrostatic hazards is required, our materials are: | |||
| ESD Series | |||
| TYPE | Material | Processing method | Application |
| ESD ENGEERING PLASTICS COMPOUND: | PA | Injection | Rod, sheet, IC trays, housings, electronic components, etc |
| PC | |||
| PC/ABS | |||
| PBT | |||
| POM | |||
| PPO/PPE | |||
| ESD SPECIAL PLASTICS COMPOUND: | PPS | electrical & eletronics components, Auto parts, medical equipment, etc | |
| PEI | |||
| PES | |||
| PSU | |||
| PEEK | |||
| LCP | |||
| ESD GENERAL PLASTICS COMPOUND | ABS | Injection, extrusion | Rod, sheet, film, tube, etc |
| PP | |||
| PS | |||
| PE | Injection, extrusion, blowing | ||
| ESD THERMOPLASTIC ELASTOMER | TPE | Injection, extrusion | Auto parts, extruded products, eletrical & eletronics components, traffic equipment |
Why choose us
(1) Easy to handle and disperse, no dust
No grinding is necessary. Under high-speed dispersion, basic painting occurs between 30 and 45 minutes. It is enough to have high-speed dispersion equipment without any need to invest large amounts of money to buy grinding equipment. It can be produced at any scale, from mass production to the laboratory. In addition, the inventory can be significantly reduced. Also, when cleaning and changing colors, it will be easier to clean the dispersion equipment.
(2) Available from unique technical merits and the most complete humidity of the pigment
With the techniques, our pigment will make the carrier resin more humid. Therefore, it will give more luster and better transparency. As a result, foam and adhesion are reduced due to poor pigment moisture.
(3) The best stability
The continuous quality has been significantly improved between one batch of merchandise and the other and also the stability of reserved colors. In addition, the cost of quality inspection is reduced.
